Product Category : Display Modules - LED Character and Numeric
Description : 4.5 DIGIT, BCD DISPLAY RED
Marketing Price : $ 24.00000
Our Price : Quote by Email
Datasheet :
DSD-40BCD-RS-C.pdf
| Internal Part Number | EIS-DSD-40BCD-RS-C | |
| Condition | New & Unused, Original Sealed | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | DSD-40BCD.sldprtDSD-40BCD.stpDSD-40BCD.igsDSD-40BCD.pdf | |
| Standard Package | 12 | |
| Category | Optoelectronics | |
| Family | Display Modules - LED Character and Numeric | |
| Series | - | |
| Number of Characters | 4.5 | |
| Size / Dimension | 0.920" H x 2.170" W x 0.560" D (23.37mm x 55.12mm x 14.22mm) | |
| Digit/Alpha Size | 0.52" (13.20mm) | |
| Display Type | 7-Segment | |
| Common Pin | - | |
| Color | Red | |
| Voltage - Forward (Vf) (Typ) | 5V | |
| Current - Test | 85mA | |
| Millicandela Rating | - | |
| Wavelength - Peak | 635nm | |
| Power Dissipation (Max) | 175mW | |
| Package / Case | 24-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DSD-40BCD-RS-C | |
| Related Links | DSD-40B, DSD-40BCD-RS-C Datasheet | |
